Lidix SL-250 Series

A unique concept and revolutionary design offering the most compact form factors available in the world without compromise on performance. The machines use one of the most advanced processors available for superior performance and accurate authentication and fitness sorting for multi currency sorting.
    Available on order only
    Innovative Design
    • Unique concept with revolutionary design
    • Most compact form factor available without compromising performance
    Advanced Processing
    • Uses one of the most advanced processors for superior performance
    • Accurate authentication and fitness sorting for multi-currency sorting
    Display and Tray
    • Ergonomic detachable display
    • Automatic reject tray
    Connectivity Options
    • Various interfaces for multiple connectivity options
    Versatility
    • Versatile and dynamic operation in various environments

Product Specifications

Speed
  • Value Counting
  • Up to 1,500 Notes/Min
  • Serial Number (OCR)
  • Up to 1,200 Notes/Min
  • Fitness Sorting
  • Up to 1,000 Notes/Min (F model only)
Operating Modes
  • Piece Count
  • Value Count
  • Denomination Sorting
  • Face & Orientation Sorting
  • Fitness Sorting (F model only)
Sensors
  • Dual CIS
  • IR
  • UV
  • MG
  • Ultrasonic (F Model only)
Software Upgrade
  • Offline
  • Via SD Card or USB
  • Online
  • Via LAN
Interface
  • LAN
  • USB
  • SD Card
  • RS232C
Multi-currency Processing
  • Up to 50 currencies
  • Customizable Auto-Currency Mode allows running multiple currencies at the same time
Hopper Capacity
  • 500 notes
Stacker Capacity
  • 200 notes
Reject Capacity
  • 100 notes
Display
  • 5" Full Colour LCD Touch Screen
Dimensions (W x D x H)
  • 300mm x 392mm x 298mm
Weight
  • 15 Kg
Power Supply
  • AC 110-240V, 50-60 Hz
Power Consumption
  • Standby
  • 70W
  • Operating
  • 110W
Peripherals (Optional)
  • External Customer Display
  • Thermal Printer
External Operating Conditions
  • Dust Level - Below 5 microns
  • Operating Temperature - 15 to 35 Celsius
  • Relative Humidity - 35% to 80% (non-condensing)
